NC220

Day/Night Cloud Camera, 300Mbps Wi-Fi

2.3 Appearance Description

2.3.1 Front Panel

Figure 2-1 Front Panel

 Light Sensor: The camera has a built-in internal photodetector. It is used to identify day or

night.

 Microphone: The camera has a built-in internal microphone. This microphone is hidden in

the pinhole located on the front panel.

 System LED:

Status Indication

Flashing Red

The camera starts booting up.

Solid Red

The camera has boot up, but is not connected to any network.

Flashing Green

The camera is in firmware upgrade procedure.

Solid Green

The camera is connected to a network or is transferring data.

System LED

Microphone

Light Sensor
