User Guide for the SIP-T23P/T23G IP Phone
6
LED Status
Description
Solid red (for monitoring
SCA phone)
The shared line is seized.
The shared line conversation is barged in by the
other shared line party.
Slow flashing green (for
local SCA phone)
Slow flashing red (for
monitoring SCA phone)
The shared line conversation is placed on public
hold.
Slow flashing green (for
local SCA phone)
Solid red (for monitoring
SCA phone)
The shared line conversation is placed on private
hold.
For a multi-party call, all the shared line parties
participating in this call place the shared line
conversation on hold.
Line key LED (associated with a bridged line)
The local BLA phone indicates the phone is involved in a BLA call, while the monitoring
BLA phone indicates the phone is not involved in the BLA call.
LED Status
Description
Off
The bridged line is idle.
Fast flashing green
The bridged line receives an incoming call.
Solid green (for local BLA
phone)
Solid red (for monitoring BLA
phone)
The bridged line is in conversation.
The bridged line is dialing.
The bridged line is seized.
Slow flashing green (for
local BLA phone)
Slow flashing red (for
monitoring BLA phone)
The bridged line conversation is placed on hold.
Note
Two ways to customize configurations of your SIP-T23P/T23G IP phone:
The user interface on the IP phone.
The user interface in a web browser on your PC.
The hardware components keypad and LCD screen constitute the phone user interface,
which allows the user to execute all call operation tasks and basic configuration
changes directly on the phone. In addition, you can use the web user interface to
The above introduces the default LED status. The statuses of the power indicator LED and
BLF key are configurable via web user interface. For more information, refer to
Yealink_SIP-T2_Series_T19(P) E2_T4_Series_IP_Phones_Administrator_Guide.
