Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series IP Phones
412
Parameters
Permitted Values
Default
ldap.user
String within 99
characters
Blank
Description:
Configures the user name used to login the LDAP server.
This parameter can be left blank in case the server allows anonymous to login.
Otherwise you will need to provide the user name to login the LDAP server.
Example:
ldap.user = cn=manager,dc=yealink,dc=cn
Note: It is not applicable to SIP-T19(P) E2 IP phones.
Web User Interface:
Directory->LDAP->Username
Phone User Interface:
None
ldap.password
String within 99
characters
Blank
Description:
Configures the password to login the LDAP server.
This parameter can be left blank in case the server allows anonymous to login.
Otherwise you will need to provide the password to login the LDAP server.
Example:
ldap.password = secret
Note: It is not applicable to SIP-T19(P) E2 IP phones.
Web User Interface:
Directory->LDAP->Password
Phone User Interface:
None
ldap.max_hits
Integer from 1 to
32000
50
Description:
Configures the maximum number of search results to be returned by the LDAP server.
If the value of the “Max.Hits” is blank, the LDAP server will return all searched results.
Please note that a very large value of the “Max. Hits” will slow down the LDAP
search speed, therefore it should be configured according to the available
bandwidth.
Example:
