Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series IP Phones

Navigate to:

http://<phoneIPAddress>/servlet

?p=network&q=load

Phone User Interface

Configure PPPoE on the IP phone.

Configure the user name and

password for PPPoE on the IP

phone.

Details of Configuration Parameters:

Parameters

Permitted Values

Default

network.internet_port.type

0, 1 or 2

Description:

Configures the Internet (WAN) port type for IPv4.

0-DHCP

1-PPPoE (not applicable to SIP-T42G/T41P IP phones)

2-Static IP Address

Note: It works only if the value of the parameter “network.ip_address_mode” is set to

0 (IPv4) or 2 (IPv4 & IPv6). If you change this parameter, the IP phone will reboot to

make the change take effect.

Web User Interface:

Network->Basic->IPv4 Config

Phone User Interface:

Menu->Settings->Advanced Settings (default password: admin) ->Network->WAN

Port->IPv4

network.pppoe.user

String within 32

characters

Blank

Description:

Configures the user name for PPPoE connection.

Example:

network.pppoe.user = Xmyl0592123

Note: It works only if the value of the parameter “network.ip_address_mode” is set to

0 (IPv4) or 2 (IPv4 & IPv6), and "network.internet_port.type" is set to 1 (PPPoE). If you

change this parameter, the IP phone will reboot to make the change take effect.

Web User Interface:

Network->Basic->IPv4 Config->PPPoE->User Name

Phone User Interface:
