Yealink SIP-T23P [502/841] Details of configuration parameters

Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series IP Phones

486

Details of Configuration Parameters:

Parameters

Permitted Values

Default

multicast.listen_address.X.ip_address

(X ranges from 1 to 10)

IP address: port

Blank

Description:

Configures the multicast address and port number that the IP phone listens to.

Example:

multicast.listen_address.1.ip_address = 224.5.6.20:10008

Note: The valid multicast IP addresses range from 224.0.0.0 to 239.255.255.255.

Web User Interface:

Directory->Multicast IP->Multicast Listening->Listening Address

Phone User Interface:

None

multicast.listen_address.X.label

(X ranges from 1 to 10)

String within 99

characters

Blank

Description:

(Optional.) Configures the label to be displayed on the LCD screen when receiving

the multicast paging calls.

Example:

multicast.listen_address.1.label = Paging1

Web User Interface:

Directory->Multicast IP->Multicast Listening->Label

Phone User Interface:

None

multicast.receive_priority.enable

0 or 1

Description:

Enables or disables the IP phone to handle the incoming multicast paging calls

when there is an active multicast paging call on the IP phone.

0-Disabled

1-Enabled

If it is set to 0 (Disabled), the IP phone will ignore the incoming multicast paging

calls when there is an active multicast paging call on the IP phone.

If it is set to 1 (Enabled), the IP phone will receive the incoming multicast paging call

with a higher or equal priority and ignore that with a lower priority.
