Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series IP Phones

564

2. Press or , or the Switch soft key to select the desired value from the LLDP

Status field.

3. Enter the priority value (1-3600s) in the Packet Interval field.

4. Press the Save soft key to accept the change.

The IP phone reboots automatically to make settings effective after a period of time.

CDP (Cisco Discovery Protocol) allows IP phones to receive and/or transmit

device-related information from/to directly connected devices on the network that are

also using the protocol, and store the information about other devices.

When CDP feature is enabled on IP phones, the IP phones periodically advertise their

own information to the directly connected CDP-enabled switch. The IP phones can also

receive CDP packets from the connected switch. When the VLAN configurations on the IP

phones are different from the ones sent by the switch, the IP phones perform an update

and reboot. This allows the IP phones to be plugged into any switch, obtain their VLAN

IDs, and then start communications with the call control.

Procedure

CDP can be configured using the configuration files or locally.

Configuration File

<y0000000000xx>.cfg

Configure CDP.

Parameters:

network.cdp.enable

network.cdp.packet_interval

Local

Web User Interface

Configure CDP.

Navigate to:

http://<phoneIPAddress>/servle

t?p=network-adv&q=load

Phone User Interface

Configure CDP feature.

Details of Configuration Parameters:

Parameters

Permitted Values

Default

network.cdp.enable

0 or 1

Description:

Enables or disables the CDP (Cisco Discovery Protocol) feature on the IP phone.

0-Disabled
