User Guide for the SIP-T19(P) E2 IP Phone
2
Hardware component instructions of the SIP-T19(P) E2 IP phone are:
Item
Description
①
LCD Screen
Shows information about calls, messages, soft keys,
time, date and other relevant data:
• Call information—caller ID, call duration
• Icons (for example, )
• Missed call text or second incoming caller information
• Prompt text (for example, "Saving config file!")
• Time and date
②
Power Indicator LED
Indicates phone power status and phone status.
③
Soft Key
Label automatically to identify their context-sensitive
features.
④
Scroll through the displayed information.
Confirms actions or answers incoming calls.
⑤
Message Key
Accesses voice mails.
⑥
Headset Key
Toggles the headset mode.
⑦
Mute Key
Mutes or un-mutes an active call.
⑧
Transfer Key
Transfers a call to another party.
⑨
Speakerphone Key
Toggles the hands-free speakerphone mode.
⑩
RD Key
Redials a previously dialed number.
⑪
Volume Key
Adjusts the volume of the handset, headset, speaker,
and ringer.
⑫
Keypad
Provides the digits, letters and special characters in
context-sensitive applications.
⑬
Speaker
Provides ringer and hands-free (speakerphone) audio
output.
⑭
Hookswitch Tab
Secures the handset in the handset cradle when the IP
phone is mounted vertically. For more information on
how to adjust the hookswitch tab, refer to
Yealink Wall
Mount Quick Installation Guide for Yealink IP Phones
.
⑮
Hookswitch
Picking up the handset from the handset cradle, the
hookswitch bounces and the phone connects to the line,
laying the handset down on the handset cradle, the
phone disconnects from the line.
Icons appearing on the LCD screen are described in the following table:
