Windoro wcr-i001 yellow [11/18] Product features and components
![Windoro wcr-i001 yellow [11/18] Product features and components](/views2/1192362/page11/bgb.png)
Product Features and Components
Please be aware of the features and components of this product. Since this product contains strong permanent magnets, if you are not
aware of the information below, you can be seriously injured or the product can be damaged.
GBDEIT
11
www.iwindoro.com
1
5
3 4
6
2
WINDORO inside/outside bodies
WINDORO consists of an inside navigation device and an outside
cleaning tool.
1
WINDORO Detergent
Pour it into the inlet of the outside cleaning tool to a maximum of
40 millilitres. You will need to use our specific WINDORO detergent only.
If you use other detergents, it can cause imperfect cleaning or operation faults.
4
WINDORO Microfiber pads
There are twelve microfiber detachable pads included with the units.
After using them, thoroughly wash them for reuse. Use WINDORO pads
only. The magnetic force of the product is adjusted to the thickness
of the WINDORO pads, hence if you use other pads, it can cause
imperfect cleaning, operation faults, or the product to fall.
5
WINDORO Edge cleaning kit
Edge pad+Fix plate. The Edge cleaning kit can be used to clean the edge
of the window, attached to the edge of the outside cleaning tool.
Only the Edge cleaning kit can be used for Windoro.
6
The WINDORO Adapter
The Y-type adapter is only for WINDORO. You can use it to charge
the inside and outside devices at the same time.
3
One Remote Controller
After attaching the WINDORO device to the window, you can use the
remote controller inside to operate the product safely and conveniently.
2
2.9kg (IN: 1.6kg, OUT: 1.3 kg) 3.2kg (IN: 1.8kg, OUT: 1.4 kg)
[IN] 218x211x51mm, [OUT] 210x208x47mm
thickness 5~15mm thickness 16~28mm
8 centimeters per second
Less than 25 Watts
Rated voltage AC 110/220v, voltage DC 15v, 1.5A
Li-ion body(11.1v 2200mAh), out (7.4v 2200mAh)
Around 150 minutes
Around 120 minutes
IR receiver system
Zigzag
Less than 60dB
Weight
Size
Thickness Criteria
Moving speed
Voltage
Adapter
Battery
Charging time
Usage time
Remote control
Cleaning mode
Noise
WINDORO for Single Panes WINDORO for Double Panes
