DEIT GB
Part Names and Functions
Inside Navigation
8
www.iwindoro.com
Bottom – strong permanent magnet.
D
B
A
C
E
1
4
6
2
3
5
7
Area to receive signals
from the remote control.
POWER/STOP : ON/OFF button
Press the button for more than 2 seconds, and the product will power
on with a beeping sound. Press it for more than 2 seconds once again,
and the product will power off with a beeping sound.
A
Magnetic force controller
Turn the controller left or right to set the optimum magnetic force,
while checking if the LED light shows the force is strong or weak.
1
Handle
Hold the handle when you attach the product. Otherwise, fingers can be
squeezed between the product and the window which will cause an injury.
4
Bumper
When the bumper sensors reach the end of the inside navigation area,
the product will move in the opposite direction. Strong pressure on the
bumpers can cause an operation fault.
5
Running Wheels
Before and after using the product, remove dust and foreign substances
from the wheels.
6
Side Wheels
Before and after using the product, remove dust and foreign substances
from the wheels.
7
Charging Port
Charge the product using a qualified adapter.
3
Power
Magnetic force is maintained regardless of whether the power is on or off.
2
START/PAUSE : Button to start cleaning or pause
Press the button for more than 2 seconds when the product is in stop
mode, and the product will start cleaning. If you press the button when
the product is working, it will pause cleaning.
B
CONTROL : Optimum magnetic force lights
RED: Adjust the magnetic force properly in order to use the product.
GREEN: The machine is at the optimal force level.
C
STATE : Signal lamp
This lamp twinkles every second when the inside and outside devices
successfully send and receive signals from each other.
D
CHARGE (IN/OUT) : Embedded battery lamp
Its color changes to green, yellow and red in turn. Recharge the product
when the lamp is red. When the product uses 80% of the battery, it will
return to the initial place it was attached and stop.
E
