TA1600/2400/3200 User Manual

18/66

end of the hunting group is reached, the hunting starts over at the first local users.

 Linear

Linear hunting is also referred to serial hunting. In linear hunting, calls are always

delivered to the first FXS users, unless it is busy, then the second, third, and so

on.
