TA100/200 User Manual
6/52
Installation
This chapter provides the following sections:
TA100/200 Packing List
Specifications and Operating Environment
Connecting Your TA100/200
TA100/200 Packing List
Upon receiving Yeastar TA100/200 gift box, please open the package and check if all
the items are supplied as TA100/200 Packing List. If there is any problem, please
contact your provider.
Table 2-1 TA100/200Packing List
Item
Unit
QTY
Description
TA100/200
PC
1
TA100/200 device unit.
USB power adapter
PC
1
USB cable
PC
1
Network cable
PC
1
Warranty card
PC
1
With Serial Number printed for Repair &
Return.
Quick installation guide
PC
1
Specifications and Operating Environment
Table 2-2 Specifications and Operating Environment
TA100/200
Description
Size (L×W×H)
85 mm × 58 mm × 24 mm
Power Supply
DC 5V,1A
Operating Temperature
0°C to 40°C, 32°F to 104°F
Storage Temperature
-20°C to 65°C, 4°F to 149°F
Humidity
10% to 90% (non-condensing)
