NeoGate TG Series User Manual
42/62
status of this account will be unmonitored.
Transport
This will be the transport method used by the
extension. The options are UDP (default) or TCP or TLS.
DTMF Mode
RFC2833, Info, Inband, Auto.
2) VoIP Trunk
In this mode, you can register NeoGate TG to provider via the trunk details with
authorization details.
Figure 7-14
Items
Description
Trunk Type Choose trunk mode to register to provider
Type
Choose the type of this trunk, SIP or IAX
Provider Name
Input the name of provider
Hostname/IP
Service provider’s hostname or IP address,
5060 is
the standard port number used by SIP protocol. Don’t
change this part if it is not required.
Domain VoIP provider’s server domain name
User Name Username of SIP account
Authorization Name
Used for SIP authentication, it’
s the same as user
name generally.
Password
Password of SIP account
