NeoGate TG Series User Manual
47/62
Figure 7-20
Items
Description
UDP Port
Port used for SIP registrations, Default is 5060
TCP Port
Port used for SIP registrations, Default is 5060
TLS Port
Port used for SIP registrations, Default is 5061
TLS Verify Server
When using NeoGate TG as a TLS client, whether or
not to verify server’s certificate. It is
“No” by
default.
TLS Verify Client
When using NeoGate TG as a TLS server, whether or
not to verify client’s certificate. It is “No” by default.
TLS Ignore Common
Name
Set this parameter as
“No”, then common name
must be the same with IP or domain name.
TLS Client Method
When using NeoGate TG as TLS client, specify the
protocol for outbound TLS connections. You can
select it as tlsv1, sslv2 or sslv3.
RTP Port Start Beginning of RTP port range
RTP Port End End of RTP port range
DTMF Mode
Set default mode for sending DTMF. Default setting:
rfc2833
Max
Registration/Subscription
Time
Maximum duration (in seconds) of a SIP
registration. Default is 3600 seconds.
Min
Registration/Subscription
Minimum duration (in seconds) of a SIP registration.
Default is 60 seconds
