NeoGate TG Series User Manual
57/62
2) Advanced mode
Figure 7-33
When simple mode is set as “No”, you can check the advanced settings.
Items
Description
Route name
A name for this route
Call Source
Choose the trunk where incoming call comes from
Inbound caller pattern
Match the prefix of caller ID for incoming calls.
Hover the pointer over to read tips.
DID number
Define the expected DID Number if this trunk
passes DID on incoming calls. Leave this field blank
to match calls with any or no DID info. You can also
use
pattern matching to match a range of
numbers.
DID Associated Number
Define the extension for DID number. You can only
input number and “-” in this field, and the format
can be xxx or xxx-xxx. T
he count of the number
must be only one or equal the count of
the DID
number
