NeoGate TG Series Installation Guide

11/16

3. NeoGate TG Series Installation

To avoid unexpected accident, personal injury or device damage, please read the following

instructions before installing NeoGate TG Series Gateway.

3.1 Placement Instructions

 Ambient Temperature: to avoid overheating, please do not run NeoGate TG Series in the

place where the ambient temperature is above 104°F (40°C).

 Ventilation: please make sure that the device has good ventilation around.

 Anti-jamming: there may be some sources of interference that might affect the normal

running of NeoGate. It’s highly recommended that the device

 Should be placed away from high-power radio, radar transmitters and high frequency,

and high-current devices.

 Is using independent power junction box and effective anti-grid interference measures

have been taken.

 Mechanical load: Please make sure that the device is placed steadily to avoid any accident

that might cause damage. If placed on the desktop, please ensure it is horizontally placed.

 Radio frequency: because of the radio frequency, please put the device at least 50 cm away

from human

body.

3.2 Installation Instructions

After placing NeoGate in a suitable place, please connect the power adapter and all other cables

to complete the installation.

3.2.1 Connection of Ethernet Ports

NeoGate TG Series provides one 10/100M adaptive RJ45 Ethernet LAN port.

 LAN Port Connection

Connect one end of a network cable to the LAN port of NeoGate, and the other end to any

port of company’s LAN switch/router.

If the LAN port is connected to PC directly (not via a switch), please use cross-over cable.

3.2.2 Connection of GSM ports

NeoGate TG Series, available with four models, supports 1, 2, 4, 8, 16 GSM ports. To use the GSM

ports, you need to insert the SIM card and connect the antenna.
