NeoGate TG Series Installation Guide
8/16
Figure 2-5 NeoGate TG1600 Front Panel
Figure 2-6 NeoGate TG1600 Rear Panel
LED
Indication
Status
Description
Power Power status On The power is switched on.
Off The power is switched off.
RUN
NeoGate status
Blinking
NeoGate is running properly.
Not
Blinking/Off
NeoGate goes wrong.
GSM PORT STATUS
ANTENNA
SIM CARD SLOT
PROTECTIV
POWER INLET
POWER SWITCH
RUN
CONSOLE
RESET
POWER
LAN
