Parts
Parts Parts
Parts
EQm EQm
EQm
Parts Parts
Parts
1.Applythreadsealanttoallnon-swivelpipe
threads.
2
Applyanti-seizetothreads.
3
Torqueto60+/-5ft-lb(81.3+/-6.7N•m)
withpotpressurized.
4
Torqueto15+/-2ft-lb(20.3+/-2.7N•m)
5
Applyanti-seizetoenclosuremounting
studs.
6
Torqueto25–30ft-lb(34–40.6N•m)
8
Applyanaerobicsealanttothreads.
343A3489C
