Instructions
- For series progressive, oil and grease lubrication -
Models/Maximum Pressure
Table 1: Maximum Pressure
Lube Points
Table 2: MGO Series-Flo Divider
Maximum Operating Pressures
Important Safety Instructions
Read all warnings and instructions in this
manual. Keep these instructions.
Divider Type
Maximum
Operating
Pressure kPSI
(MPa, bar)
Maximum
Sections
MD
3.0 (20.7, 207) 2
MJ
2.0 (13.8, 138) 8
MJSS
2.0 (13.8, 138) 8
MSP
3.5 (24.1, 241) 8
MHP
6.0 (41.4, 414) 8
MHH
7.5 (51.7, 517) 8
ZMSP
3.0 (20.7, 207) 6
MX
3.0 (20.7, 207) 10
MXP
3.0 (20.7, 207) 10
MGO
See Table 2 11
Maximum Operating
Pressure kPSI (MPa, bar) Number of Sections
6.0 (41.4, 414)
3 to 7
5.5 (37.9, 379)
8
4.0 (27.6, 276)
9
4.5 (31.0, 310)
10
4.0 (27.6, 276)
11
312497A
Trabon
Divider Valves
Содержание
- Instructions 1
- Trabon divider valves 1
- Warning 2
- Warnings 2
- Component identification 3
- Pressure relief procedure 3
- Table 3 typical divider valve combinations 3
- Caution 4
- Filling master to secondary lube lines 4
- Filling secondary to lube point lines 4
- Prefilling lubricant distributor lines 4
- Filling master divider valve 5
- Caution 6
- Page 10 adding or replacing any component in module in a secondary divider valve assembly 6
- Page 6 replacing line between a secondary divider valve and lube point 6
- Page 7 replacing a line between the master divider valve and a secondary divider valve 6
- Page 8 replacing a line between pump and master divider valve 6
- Page 9 adding or replacing any component in a master divider valve assembly 6
- Purging air from the system 6
- Repair 6
- Section 1 purging air from secondary divider valve lube to lube point lines 6
- Section page air purging after 6
- Steps 1 6 refer to 6
- Section 2 purging air from master to secondary divider valve lube lines 7
- Steps 1 9 refer to 7
- Section 3 purging air from pump to master divider valve lines 8
- Steps 1 3 refer to 8
- Section 4 purging air after adding or replacing a master divider valve module 9
- Steps 1 7 refer to 9
- Section 5 purging air after adding or replacing a secondary divider valve module 10
- Steps 1 8 refer to 10
- Automatic relief indicator 11
- Caution 11
- Locating and repairing blockages 11
- Performance indicators 11
- Reset indicator with memory 11
- Rupture indicator 11
- Caution 12
- Locating and repairing blockages 12
- Assembly torque ft lbs 13
- Caution 13
- Inlet 10t 20s 10t 30s end 13
- Mj md mv mvh msp mh mx mxp mgo 13
- Page 3 13
- Table 4 torque values see 13
- Contamination blockage 14
- Separation blockage 14
- Divider valve mj mj ss ms mh ms nickel mx mxp mgo 15
- Part numbers 15
- 0 8 ccm torque ratings assembly bolts 8 9 ft lbs enclosure plugs 11 13 ft lbs indicator plug 15 ft lbs outlet plugs 6 7 ft lbs 16
- 1 1 ccm md 6 0 60 in 16
- 312497a 16
- Dimensions 16
- Material steel pressure max 3 000 psi 207 bar lubricant oil or grease net weight approx 1 lb 8 oz 0 8 kg volume lubricant to cycle divider valve one complete cycle md 2 md 3 md 4 0 80 in 16
- Md series 16
- Specifications 16
- Technical data 16
- Dimensions 17
- Mj series 17
- Specifications 17
- Technical data 17
- 312497a 18
- Dimensions 18
- Mh series 18
- Specifications 18
- Buna n o rings 422 010 060 19
- Technical data 19
- Viton o rings 527 000 840 19
- Dimensions 20
- Msp series 20
- Technical data 21
- Dimensions 22
- Mx series 22
- Specifications 22
- Technical data 22
- Dimensions 24
- Mxp series 24
- Technical data 25
- Dimensions 26
- Mgo series 26
- Technical data 27
- For complete warranty information contact your local graco distributor call graco customer service at 1 800 690 2894 or visit our website www graco com 28
- Standard lubriquip warranty 28
