Graco Manzel MHH [18/28] Mh series
![Graco Manzel MHH [18/28] Mh series](/views2/1193421/page18/bg12.png)
Specifications
18 312497A
MH Series
Dimensions
INDICATOR PORT
(TYPICAL)
,
MOUNTING SCREW
(TYPICAL)
LUBE
INLET
.281 (7.137) DIA
(4) MTG HOLES
3.000
(76.2)
1.750
(44.4)
"A"
2.188
(55.56)
1.656
(42.06)
1.500
(38.1)
.781
(19.9)
1.125
(28.58)
.406
(10.31)
.734
(18.85)
OUTLET IS PLUGGED
ON ONE SIDE WHEN
WORKING SECTION IS
SINGLED
LUBE
OUTLET
(TYPICAL)
PISTON ENCLOSURE PLUG (TYPICAL)
TIE ROD AND NUT
(TYPICAL)
.28
(7.1)
.484
(12.3)
.484
(12.3)
.625
(15.9)
.922 (TYP)
(23.41)
",%%$3#2%73
ti11480
