Parts
EQ400T3 EQ400T3
EQ400T3
Parts Parts
Parts
List List
List
Ref. Ref.
Ref.
Part Part
Part
Description Description
Description
Qty. Qty.
Qty.
1
TRAILER,GL10,electric
brakes
1
2
COMPRESSOR,375
cfm,skidmount
1
5
17L039
CABLE,battery,
deadman,trailer
1
6
MODULE,EcoQuip,
EQC,elite,trailer
1
10
EQ1152WASHER,at,1/2,sst
8
11
EQ1519BOLT,hexhd,1/2x1-1/2,
sst
4
12
EQ1475
NUT,lock,nyloninsert,
1/2,sst
4
13
EQ1003
VALVE,ball,3/4npt,sst1
14
EQ1846COUPLER,3/4qd(f),3/4
npt(m),br
1
15190724NIPPLE,sst1
17
EQ1848HOSE,water,EQ2040,
3/4in.ID
1
1817K878
HOSE,air,trailersystem,
GL10
1
19128934
FITTING,swivel,elbow,
1-1/2npt,cs
1
21129009
FITTING,elbow,90,mxf,
cs
1
Ref. Ref.
Ref.
Part Part
Part
Description Description
Description
Qty. Qty.
Qty.
2724Z156KIT,replacement,tool
box
1
2824Z156
INSERT,foam,toolbox,
EcoQuip
1
2917K025
STRAINER,pressurepot
2
30
EQ1844FUSE,blade,atc,3A
2
3117J331
GASKET,camlock,buna,
1.0
2
3217L633
TOOL,EQ,wrench,2-7/8
2
33206994
FLUID,TSL8oz.bottle
1
3417J958
TOOL,pressure
verication
1
35502598
GASKET,sanitary(ptfe)
2
36680454
GASKET,sanitarytting
6
3717D786
CABLE,safetyitem,hose,
whip-c
4
3817D787
PIN,safetyitem,hose,
hairc(6pack)
4
39
EQ1051GASKET,blastnozzle
2
41128734
GAUGE,oat
1
▲
ReplacementDangerandWarninglabelsare
availableatnocost.
NOTE: NOTE:
NOTE:
ForinformationregardingKAESERcompressorsorcompressorenginesseetheKAESERcompressor
manual,whichisincludedwithEcoQuip2TrailerSystems(orvisitus.kaeser.com).
3A3489C49
