Graco Viscount I 1000 Pump Инструкция по эксплуатации онлайн
Instructions–Parts List
307622J
EN
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
STAINLESS STEEL
Viscountr I 1000 Pump
Hydraulic pumps designed for medium viscosity corrosive materials.
For professional use only.
1000 psi (6.9 MPa, 69 bar) Maximum Hydraulic Input Pressure
1000 psi (6.9 MPa, 69 bar) Maximum Fluid Outlet Pressure
Part No. 218077, Series B
U.S. Patent No. 4,383,475
Patent 1984 Canada
Brevete 1984
Foreign Patents Pending
03833
