Graco Python 3/4" [41/56] Timing valve assembly b32069 parts list
Parts
3A3101D 41
Timing Valve Assembly (B32069) Parts List
* Parts included in Kit B32153 (purchase separately).
‡ Parts included in Kit B32195 (purchase separately).
Ref. Part Description Qty.
101 B32193 Lower Housing 1
102* -- Seal Cartridge 2
103* -- Spool 1
104* -- Ball, 316 stainless steel;
included with lower and upper
housing (ref. 101 & 110)
1
105* -- Seal, Spool 4
106* -- O-ring; included with lower
housing (ref. 101)
3
107* -- Piston 1
108* -- Seal, Piston 1
109 -- Pin; included with spring
retainer (ref. 112)
1
110 B32194 Upper Housing 1
111‡ -- Screw, 316 SST, 1/4-20 2
112 B32196 Spring Retainer 1
113 -- Dowel Pin; included with lower
housing (ref. 101)
2
114 -- O-ring; included with spring
retainer (ref. 112)
1
115 B32197 Spool Return Spring 1
116 -- Nipple Fitting, 1/8 NPT;
included with lower housing
(ref. 101)
1
117 B32199 Timing Valve Needle 1
118 -- O-ring; included with timing
valve needle (ref. 117)
1
119 -- Internal Ring, Stainless Steel;
included with timing valve nee-
dle (ref. 117)
1
120 -- Knob Spring; included with tim-
ing valve needle (ref. 117)
1
122 -- Needle Knob; included with tim-
ing valve needle (ref. 117)
1
123‡ -- Set Screw; included with timing
valve needle (ref. 117)
2
124* -- O-ring 4
125* -- Seal Cartridge Retainer 1
126 -- Grease Lubricant (not shown)
127 -- Pipe Sealant (not shown)
129* -- Bottom Seal Retainer 1
130* -- Cartridge Spacer 1
Ref. Part Description Qty.
