Graco Python 3/4" [43/56] Python pump dimensions
Dimensions
3A3101D 43
Dimensions
Python Pump Dimensions
FIG. 30 Python Pump Dimensions
A B C D E
13.26 in.
(33.7 cm)
5.3 in.
(13.5 cm)
2.34 in.
(5.9 cm)
2.3 in.
(5.8 cm)
9.125 in.
(23.2 cm)
