Models and Approvals
4 334513D
Wolverine Hazardous Location
A267xx
A297xx
230/460 VAC
3Phase
Large
3/16 in. 10,000 (69.0, 690)
Not approved for use in Euro-
pean explosive atmospheres
or hazardous locations
1/4 in. 6000 (41.3, 413)
3/8 in. 2500 (17.2, 172)
1/2 in. 1250 (8.6, 86)
5/8 in. 900 (6.2, 62)
3/4 in. 600 (4.1, 41)
Models Voltage Motor Plunger Size
Maximum Working Pressure
psi (MPa, bar) Approvals
Models Voltage Motor Plunger Size
Maximum Working Pressure
psi (MPa, bar)
Approvals
A272xx 12 VDC
Hazardous
Location
3/16 in. 10,000 (69.0, 690)
Class I, Group C & D,
Class II, Group F & G
1/4 in. 6000 (41.3, 413)
3/8 in. 2500 (17.2, 172)
1/2 in. 1250 (8.6, 86)
5/8 in. 900 (6.2, 62)
3/4 in. 600 (4.1, 41)
A273xx 24 VDC
Hazardous
Location
3/16 in. 10,000 (69.0, 690) Not CE approved for use in
European explosive atmo-
spheres
Class I, Group C & D,
Class II, Group F & G, T3C
1/4 in. 6000 (41.3, 413)
3/8 in. 2500 (17.2, 172)
1/2 in. 1250 (8.6, 86)
5/8 in. 900 (6.2, 62)
3/4 in. 600 (4.1, 41)
A275xx 115/230 VAC
Hazardous
Location
3/16 in. 10,000 (69.0, 690)
Class I, Group C & D,
Class II, Group F & G
1/4 in. 6000 (41.3, 413)
3/8 in. 2500 (17.2, 172)
1/2 in. 1250 (8.6, 86)
5/8 in. 900 (6.2, 62)
3/4 in. 600 (4.1, 41)
A277xx
230/460 VAC
3Phase
Hazardous
Location
3/16 in. 10,000 (69.0, 690) Not CE approved for use in
European explosive atmo-
spheres
Class I, Group C & D,
Class II, Group F & G, T3B
1/4 in. 6000 (41.3, 413)
3/8 in. 2500 (17.2, 172)
1/2 in. 1250 (8.6, 86)
5/8 in. 900 (6.2, 62)
3/4 in. 600 (4.1, 41)
