Graco Wolverine Advanced Simplex [6/62] Configuration number matrix
![Graco Wolverine Advanced Simplex [6/62] Configuration number matrix](/views2/1193746/page6/bg6.png)
Models and Approvals
6 334513D
Configuration Number Matrix
Check the identification plate (ID) for the 12-digit Configuration Number of your pump. Use the following matrix to
define the components of your pump.
NOTE: Not all combinations are possible.
Wolverine Assembly Configuration Code
Sample Configuration Number: CI-12S-3XD-3XD-C
NOTE: Effective Date Code “X 2516” (see F
IG. 1), if your configuration does not match this format, you have an older
pump assembly configuration. See manual 334513, rev C.
NOTE: Not all combinations are possible.
NOTE: Approvals information is found on pages 3 and 4. Models can be identified using the Voltage and Motor con-
figuration codes and columns.
FIG. 1 Example of the Wolverine Assembly Identification Plate
A29150 CI-12S-3XD-3XD-C ########
A
1500
(
10.3
)
1500
(
10.3
)
# ####
Graco Inc., P.O. Box 1441
Mpls, MN 55440 USA
Model Number
Configuration Number
Date Code
Side 1 Side 2
CI 12 S 3 X D 3 X D C
Chemical
Injection
Voltage Motor Plunger
Size
Plunger
Coating
Seal Mate-
rial
Plunger
Size
Plunger
Coating
Seal Mate-
rial
Qualifier
Side 1 Side 2
Voltage Motor
Plunger
Size
Plunger
Coating
Seal
Material
Plunger
Size
Plunger
Coating
Seal
Material
Qualifier
12 12 VDC S Small 1 3/16” C Ceramic A FKM 0 None
(Advanced
Simplex)
0 None
(Simplex)
0 None
(Simplex)
0None
24 24 VDC L Large 2 1/4” X Chromex B FKMETP 1 3/16” C Ceramic A FKM C Cycle
Count
1A 115 VAC H Hazardous
Location
33/8”
C HNBR 2 1/4” X Chromex B FKMETP
2A 230 VAC 51/2” D FFKM 3 3/8” CHNBR
3A 115/230 VAC 65/8” 51/2” DFFKM
4A 230/460 VAC,
3 Phase
73/4” 75/8”
B None
(Basic)
