Graco S20 [13/42] L20c 2in elevator
![Graco S20 [13/42] L20c 2in elevator](/views2/1193758/page13/bgd.png)
Component Identification
313526L 13
L20c 2in. Elevator
Key:
CA Elevator Cart
CB Air Motor
CC Displacement Pump
CD Platen
CE Enclosed Wet Cup (behind air controls)
CF Elevator and Pump Air Controls
J Platen Bleed Port
P Pump Bleed Valve
F
IG
. 6
CF
CB
CA
CC
CD
CE
r_257032_312376_1e
CM7B1G Model Shown
P
J
Lift Location
