![Graco 15:1 President [6/8] Presiden](/views2/1193522/page6/bg6.png)
President
®
Pneumatic 2-Ball Piston Pumps
Model 3:1 4:1 10:1 15:1 30:1 46:1
PUMP SPECIFICATIONS
Output per cycle
630 cc 500 cc 189 cc 112 cc 62 cc 36 cc
Maximum working
pressure psi (bar, MPa)
360
(25, 2.5)
400
(28, 2.8)
1800
(124, 12.4)
1800
(124, 12.4)
3600
(250, 25)
4600
(317, 31.7)
Maximum air input
pressure psi (bar, MPa)
120 (8, 0.8) 100
(7, 0.7)
180 (12, 1.2) 120 (8, 0.8) 120 (8, 0.8) 100
(7, 0.7)
Output at 60 CPM gpm (lpm)
10 (37.8) 8 (30.2) 3 (11.3) 1.8 (6.8) 1 (3.8) 0.55 (2.1)
INLET/
OUTLET
Pump inlet size
1-1/2 npt(f) 1-1/2 npt(f) Stubby: 3/4 npt(f)
Drum: No intake thread
3/4 npt(m) 316 SST: 3/4 npt(f)
Other Models: 3/4 npt(m)
3/4 npt(m)
Pump outlet size
Stubby: 3/4 npt(m)
Drum: 1 npt(f)
1 npt(f) Models 239326,224347,
224348: 3/4 npt(f)
Models 224342, 224348: 1/2 npt(f)
1-1/2 npt(f) 316 SST: 1/4 npt(f)
Other Models: 3/8 npt(f)
3/8 npt(f)
MANUALS
Pump manual assembly
307674 307986 308116 (Model 224342)
308117 (Models 224346, 224347)
308118 (SST Drum Pumps)
308738 (CS Drum Pumps)
306936 306769 (316 SST model)
308106 (304 SST model)
306981 (CS models)
307619
Type Seals 3:1 4:1 10:1 15:1 30:1 46:1
PUMP CONSTRUCTION
CARBON STEEL
Stubby 4 Leather/1 PTFE 237142
Stubby 3 Leather/ 2 PTFE 237143
Stubby 3 UHMWPE/2 Leather 223184
Stubby PTFE/Leather 217580 223586
Drum 4 Leather/1 PTFE 237144
Drum 3 UHMWPE/2 Leather 218795 223183
Drum PTFE 239326
Drum PTFE/Leather 221075
STAINLESS STEEL
Stubby 3 UHMWPE/2 Leather 218747
Stubby 5 PTFE 237146
Stubby UHMWPE/PTFE 224342
Stubby UHMWPE/Neoprene 224346
Stubby
w/Riser
Tube
UHMWPE/Neoprene 224347
Stubby
304 SST
PTFE/Leather 223843 239140
Drum 3 UHMWPE/2 Leather 218795
Drum 5 PTFE 237145
Drum UHMWPE/PTFE 224348
Technical Specifications and Ordering Information
Additional Lower Displacement Pumps
Lower
Displacement
Standard
Seal Repair
Standard
Displacement Rod Sleeve Housing
Pump Mat’l Kit Const. Rod Const. Housing Const.
223595 CS 239328 4 Leather/
1 PTFE
223603 SST 178898 SST
President/Monark Features and Benefits
• Reliable, low maintenance air motor
• Positive displacement, 2-ball piston design provides uniform and easily controlled delivery
• Stainless steel or carbon steel models available to handle various fluids
• Drum and stubby length models available for mounting and application flexibility
