Graco 10:1 President [7/8] Pneumatic 2 ball piston pumps

Monark

®

Pneumatic 2-Ball Piston Pumps

Part Number 218763 223186 224350 224343 224345 218956 239327 223844 223596 237958

PUMP SPECIFICATIONS

Model 1.5:1 2:1 5:1 5:1 5:1 5:1 15:1 15:1 23:1 23:1

Output per cycle 429 cc 343 cc 157 cc 157 cc 157 cc 135 cc 44 cc 44 cc 27 cc 27 cc

Maximum working

pressure psi (bar, MPa)

180

(12, 1.2)

200

(12, 1.4)

900

(62, 6.2)

600

(42, 4.2)

900

(62, 6.2)

Pump outlet size 1 npt(f) 1 npt(f) 3/4 npt(f) 1/2 npt(f) 1/2 npt(f) 3/4 npt(f) 3/8 npt(f) 3/8 npt(f) 3/8 npt(f) 3/8 npt(f)

MANUALS

Pump manual assembly 307653 307985 308118 308116 308117 307044 308739 308106 307619 307619

Lower manual 307652 307983 308118 308116 308117 307044 306981 308106 307619 307619

Motor manual 307141 307043 307043 307043 307043 307043 307043 307043 307043 307043

Type Seals 1.5:1 2:1 5:1 5:1 5:1 5:1 15:1 15:1 23:1 23:1

PUMP CONSTRUCTION

CARBON STEEL

Stubby UHMWPE/Leather 223186 239327 223596

Drum UHMWPE/Leather 223185

Drum UHMWPE/PTFE 224350

Technical Specifications and Ordering Information

Accessories

206220 Wall Bracket

For mounting President pump to wall.

207365 Wall Bracket

For mounting a President pump to a wall.

205640 Pump Floor Stand

For mounting a President pump in a suction feed system.

Adapter 206108 is required.

168085 Accessory Assembly Tool

Use to install piston assembly into cylinder (model 239326).

171818 Adjustment Tool

A 0.145 in (3.7 mm) gauge used to ensure proper clearance

between the poppets and the piston on the President air motor.

207579 Padded Pliers

For servicing President air motor trip rod.

236054 Suction Kit (Monark 1.5:1 and 2:1 only)

Use to siphon material out of 55 gal (200 l) closed-end drum.

Includes siphon tube, bung adapter, 6 ft (1.8 m) nitrile hose, 1-1/2

Use to siphon fluid from a 55 gal (200 l) drum. Includes nylon suction

hose 214961, 3/4 in ID, 6 ft (1.8 m), 3/4 in npt(f) swivel outlet fitting,

bung adapter.

208920 Siphon Kit, Aluminum (Monark 5:1 only)

Use to siphon fluid from a 5 gal (18.9 l) pail. Includes nylon suction

hose 170706, 1 in ID, 4 ft (1.2 m) long, 3/4 in npt(f) swivel outlet

fitting, inlet strainer.

President/Monark Typical Fluids Handled

• Solventborne and waterborne fluids

• High solids, plural component coatings

• Cleaning fluids

• Acid-catalyzed materials
