Graco 30:1 President Инструкция по эксплуатации онлайн
Instructions–Parts List
308106G
SEVERE–DUTY
Stainless Steel Pumps
For airless and air–assisted spraying of finishing materials.
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
See page 2 for Table of Contents.
Part No. 223843, Series A
30:1 Ratio Presidentr Pump
3600 psi (25.0 MPa, 250 bar) Maximum Fluid Working Pressure
120 psi (0.8 MPa, 8 bar) Maximum Air Input Pressure
Part No. 223844, Series A
15:1 Ratio Monarkr Pump
2700 psi (18.5 MPa, 185 bar) Maximum Fluid Working Pressure
180 psi (1.25 MPa, 12.5 bar) Maximum Air Input Pressure
MODEL 223843 SHOWN
II 2 G
T3
II 1/2 G T3
ITS03ATEX11228
0359
