15308106
Service
105
*18
*13
*9
12
*17
*18
16
*15
*7
3
14
22
6*
10
17*
8*
19
101(REF)
2
1
106
110
4
*13
8*
Fig. 4
1
3
4
2
Torque to 18–20 ft-lb (24–27 N.m)
1
Torque to 25–30 ft-lb (34–41 N.m)
2
Torque President to 25–30 ft-lb (34–41 N.m);
Monark to 15–20 ft-lb (20–27 N.m)
3
Torque to 65–75 ft-lb (88–102 NSm)
4
5
6
Lips of v-packings must face down
Lips of v-packings must face up
6
7
Torque to 75–100 ft-lb (102–136 N.m)
5
7
