Graco 30:1 President [11/24] Shutdown and care of the pump
![Graco Monark 23:1 [11/24] Operation](/views2/1193927/page11/bgb.png)
11308106
Operation
WARNING
To reduce the risk of serious injury whenever you
are instructed to relieve pressure, always follow the
Pressure Relief Procedure on page 9.
Shutdown and Care of the Pump
For overnight shutdown, relieve the pressure. Always
stop the pump at the bottom of the stroke to prevent
the fluid from drying on the exposed displacement rod
and damaging the throat packings.
Always flush the pump before the fluid dries on the
displacement rod. Relieve the pressure after flushing.
AIR MOTOR PLATE
4
Fig. 2
