Pioneer DMP-555 [18/24] Card mixing dual mode

ADVANCED OPERATIONS

CARD MIXING (dual mode)

CARD TRIM

MIXOUT

TEMPO

SYNCHRO

CARD TEMPO

(PITCH BEND)

PLAY/PAUSE

CARD CONTROL

LOOP START/

STOP

CARD CONTROL

CUE

1, ¡

3/ 7

SOURCE SELECT CD

SOURCE SELECT CARD

FOLDER

+, =

CARD CONTROL

TRACK SEARCH

4, ¢

Jog dial

Card Mix Output Settings (*)

In dual mode, the CARD MONITOR connectors output the sound from the memory

card. This output allows the user to perform track selection or check the contents of

a memory card while simultaneously playing a CD.

÷ When source selector is set to CARD (SOURCE SELECT [CARD] button in-

dicator is lighted), no sound will be output from the CARD MONITOR connec-

tors.

7 AUDIO OUT connector settings

This setting determines whether sound from a memory card’s track is output at

the AUDIO OUT connectors when the source selector is set to CD (SOURCE

SELECT [CD] button indicator is lighted).

÷ With the mix output set to OFF, perform track selection or check the con-

tents of the memory card as desired; then set to cue pause mode, and set the

MIXOUT button to ON.

Press the MIXOUT button.

÷ When the [MIXOUT] button indicator lights, the memory card’s track

sound is output at the AUDIO OUT connectors.

÷ Even if no CD is currently playing, when the [MIXOUT] button indicator

lights, the memory card’s sound is output at the AUDIO OUT connectors.

7 Adjusting card playback volume

When the source selector is set to CD (SOURCE SELECT [CD] button indi-

cator is lighted), this adjusts the sound volume of the memory card playback

heard at the CARD MONITOR and AUDIO OUT connectors.

Rotate the CARD TRIM dial.

÷ Adjustment range is –∞ to +12dB.

÷ When source selector is set to CARD (SOURCE SELECT [CARD] button

indicator is lighted), no sound is output from the CARD MONITOR con-

nectors; as a result, the CARD TRIM dial does not operate under this con-

dition.

The card mix function allows you to mix playback from a memory card with play-

back of a CD-DA.

÷ Card mix is not supported for CD-ROM.

Card Mix Playback (*)

7 Loop playback of a single track on a memory card

Use this function for seamless loop mixing of a single track on the memory

card with playback from a CD (CD-DA).

This operation is enabled when the source selector is set to CD (SOURCE SE-

LECT [CD] button indicator is lighted).

1. Load a memory card with desired track into the player.

÷ The CARD indicator will light.

÷ MMC cards created on devices equipped with security functions, or MMC

cards formatted using proprietary formats cannot be played (the CARD in-

dicator will not light when the card is loaded).

÷ The player will search for the first track on the default playlist and enter

cue pause mode at that point; the LOOP START/STOP button (3/7)

will simultaneously light.

2. Press the MIXOUT CARD CONTROL block’s TRACK

SEARCH button (4, ¢) to select the desired track

onto the memory card.

÷ The track number will change up or down, corresponding to the direction

indicated by the button pressed, and the track number and title of the first

track discovered will be displayed; the player will enter cue pause mode at

the beginning of the track.

÷ If the button is held depressed, the search will be performed continuously;

if the button is held depressed for 2 seconds or more, the speed of search

will increase.

÷ If reverse search (4) is performed from the lowest numbered track, the

search function will jump to the last (highest numbered) track.

÷ If forward search (¢) is performed from the highest numbered track,

the search function will jump to the first (lowest numbered) track.

÷ To search within a specific play list of a memory card, use the FOLDER

SEARCH button (+, =) first to designate the desired play list; in this

way, the track search function will operate on the tracks in the selected play

list. If no play list is designated, the search function will be performed within

all tracks located in the memory card.

÷ During playback, to skip to the previous track, press the 4 button twice

in succession.

3. Press the LOOP START/STOP button (3/7).

÷ When pressed from the cue pause mode, the button’s [3/7] indicator

flashes and playback simultaneously begins.

÷ When the selected track ends, playback returns to the beginning of the track

and begins again (seamless one-track loop).

÷ If the LOOP START/STOP button (3/7) is pressed during playback,

playback stops, the button’s [3/7] indicator lights and the unit enters

the cue pause mode at the beginning of the track.

÷ By making cue and loop settings beforehand, you can change the range of

the loop playback (

☞

P.16).

7 Cue point sampler

When a memory card track has been set in the cue pause mode, this function

plays the track only so long as the MIXOUT CARD CONTROL block’s CUE

button is held depressed.

This function operates when the source selector is set to CD (SOURCE SE-

LECT [CD] button indicator is lighted). When card mix play is enabled, the

MIXOUT CARD CONTROL block’s [CUE] button indicator lights.

Press the CUE button in the MIXOUT CARD CONTROL block.

÷ Playback will continue as long as the button is held depressed; when the

button is released, playback will stop and the player will return to the cue

pause mode at the beginning of the track.

÷ By setting a cue point beforehand, you can make playback begin from the

cue point when the CUE button is depressed; when the CUE button is re-

leased, playback will stop and the player will return to the cue pause mode

at the selected cue point.

Functions indicated by * cannot be used when the Digital mode switch

(DIGITAL OUT) is set to ON (and the digital output terminal is used).
