Overview

The EDS-G205 series is equipped with 5 Gigabit Ethernet ports, making it

an ideal and economical solution for demanding, high bandwidth Gigabit

Ethernet applications. In addition, the built-in relay warning function

alerts system administrators when power failures or port breaks occur.

The EDS-G205 series includes 2 models: one with an operating

temperature range of 0 to 60°C, and the other one with extended

operating temperature range of -40 to 75°C. These 2 models have passed

a 100% burn-in test to ensure that they fulfill the special needs of

industrial automation control. The EDS-G205 series can be easily

installed with DIN-Rail mounting as well as distribution boxes.

NOTE

Throughout this Hardware Installation Guide, we use EDS as an

abbreviation for Moxa EtherDevice Switch:

EDS = Moxa EtherDevice Switch

Package Checklist

Your EDS is shipped with the following items. If any of these items is

missing or damaged, please contact your customer service

representative for assistance.

• Moxa EtherDevice™ Switch

• Hardware Installation Guide

• Moxa Product Warranty booklet

Features

High Performance Network Switching Technology

• 10/100/1000BaseT(X) (RJ45), auto negotiation speed, F/H duplex

mode

• IEEE 802.3/802.3u/802.3ab.

• Store and Forward switching process type, 8K MAC address entries.

Industrial Grade Reliablity

• Power failure, port break alarm by relay output

• Redundant dual 12/24/48VDC power inputs

Rugged Design

• Operating temperature range of 0 to 60°C, or extended operating

temperature of -40 to 75°C for (-T) models

• IP30, rugged high-strength case

• DIN-Rail or panel mounting ability
