![Moxa EDS-G516E-4GSFP-T [15/16] Specifications](/views2/1195694/page15/bgf.png)
- 15 -
LED
Color
Status
Description
FAULT +
MSTR/HEAD
+ CPLR/TAIL
Rotate
Blinking
Sequentially
ABC-02-USB is importing/exporting files.
STATE +
FAULT +
MSTR/HEAD
+ CPLR/TAIL
Blinking
Switch is being discovered/located by
MXview (2 times/s).
10M/
100M
(TP)
Amber
On
TP port’s 10 or 100 Mbps link is active.
Blinking
Data is being transmitted at 10 or 100
Mbps.
Off
TP port’s 10/100 Mbps link is inactive.
1000M
(TP)
Green
On
TP port’s 1000 Mbps link is active.
Blinking
Data is being transmitted at 1000 Mbps.
Off
TP port’s 1000 Mbps link is inactive.
100M
(SFP)
Amber
On
SFP port’s 100 Mbps link is active.
Blinking
Data is being transmitted at 100 Mbps.
Off
SFP port’s 100 Mbps link is inactive.
1000M
(SFP)
Green
On
SFP port’s 1000 Mbps link is active.
Blinking
Data is being transmitted at 1000 Mbps.
Off
SFP port’s 1000 Mbps link is inactive.
Specifications
Technology
Standards
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X) and 100BaseFX
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3z for 1000BaseX
Protocols
IGMPv1/v2/v3, GMRP, GVRP, SNMPv1/v2c/v3,
DHCP Server/Client, DHCP Option 66/67/82, BootP,
TFTP, SNTP, SMTP, RARP, RMON, HTTP, HTTPS,
Telnet, SSH, Syslog, EtherNet/IP, PROFINET,
Modbus/TCP, SNMP Inform, LLDP, IEEE 1588 PTP
V2, IPv6, NTP Server/Client
MIB
MIB-II, Ethernet-Like MIB, P-BRIDGE MIB,
Q-BRIDGE MIB, Bridge MIB, RSTP MIB, RMON MIB
Group 1, 2, 3, 9
Flow Control
IEEE 802.3x flow control, back pressure flow control
Interface
RJ45 Ports 8 (EDS-G508E/EDS-G512E-4GSFP) or 12
(EDS-G516E-4GSFP) 10/100/1000BaseT(X)
Fiber Ports
4-port 100/1000BaseSFP slot
(EDS-G512E-4GSFP/EDS-G516-4GSFP only)
USB Ports
USB console port (type B connector)
USB storage port (type A connector)
Button
Reset button
LED Indicators
PWR1, PWR2, FAULT, STATE, 10/100M, 100/1000M,
MSTR/HEAD, CPLR/TAIL
Alarm Contact 1 relay output with current carrying capacity of 1 A
@ 24 VDC
Digital Input
1 input with the same ground, but electrically
isolated from the electronics.
+13 to +30V for state “1”
