- 12 -
Front Panel LEDs
The PT-510’s front panel has five LED indicators, refer to the following
table for details.
LED
Color
State
Description
PWR1 AMBER
On
Power is being supplied to power input
PWR1.
Off
Power is
not
being supplied to power
input PWR1.
PWR2
(DC model)
AMBER
On
Power is being supplied to power input
PWR2.
Off
Power is not being supplied to power
input PWR2.
Ports 1 to
10
GREEN
On
Port’s 100 Mbps link is active.
Off
Port’s link is inactive.
AMBER
On
Port’s 10 Mbps link is active.
Off
Port’s link is inactive.
FAULT RED
On
1. A relay warning event is triggered,
or
2. The PT switch is the Master of this
Turbo Ring, and the Turbo Ring is
broken, or
3. Start-up fails
Off
When a relay warning event is not
triggered.
MSTR/HEAD
GREEN
On
When the PT switch is set as the
Master of the Turbo Ring, or as the
Head of the Turbo Chain.
Blinking
The PT switch has become the Ring
Master of the Turbo Ring, or the Head
of the Turbo Chain, after the Turbo
Ring or the Turbo Chain is down.
Off
The PT switch has become the Ring
Master of the Turbo Ring, or the Head
of the Turbo Chain, after the Turbo
Ring or the Turbo Chain is down.
CPLR/TAIL GREEN
On
When the PT switch coupling function
is enabled to form a back-
up path, or
when the PT is set as the Tail of the
Turbo Chain.
Blinking
When the Turbo Chain is down.
Off
When the PT switch disables the
coupling function, or is set as a
Member of the Turbo Chain.
