ATTENTION
This is a Class 1 Laser/LED product. To avoid causing
serious
damage to your eyes, do not stare directly into the Laser Beam.
LED Indicators
The front panel of the Moxa EtherDevice Router contains several LED
indicators. The function of each LED is described in the following table:
LED
Color
State
Description
PWR1 AMBER
On
Power is being supplied to power
input P1 on the main module.
Off
Power is not being supplied to
power input P1 on the main
module.
PWR2 AMBER
On
Power is being supplied to power
input P2 on the main module.
Off
Power is not being supplied to
power input P2 on the main
module.
FAULT RED
On
When a user-configured event is
triggered.
Off
When a user-
configured event has
not been triggered.
10/100/1000M
AMBER
On
TP or FX port’s 10/100 Mbps link is
active.
Blinking
Data is being transmitted at
10/100 Mbps.
Off
TP or FX port’s 10/100 Mbps link is
inactive.
GREEN
On
TP or FX port’s 1000 Mbps link is
active.
Blinking
Data is being transmitted at 1000
Mbps.
Off
TP or FX port’s 1000 Mbps link is
inactive.
WAN/DMZ
(EDR-G903
only)
AMBER
On
The WAN2/DMZ port is set to the
“WAN” function.
Off
The WAN2/DMZ port is disabled.
GREEN
On
The WAN2/DMZ port is set to the
“DMZ” function.
Off
The WAN2/DMZ port is disabled.
