New Function!

When the timer key is pressed for 3 secs digital display starts to change.

Air-circulation system of the chimney hood becomes active. The chimney

hood runs for 10 minutes in the lowest speed. Then the system automatically

shuts down.

5.2.Operating the Chimney Hood

Chimney hood is used in ducted and non-ducted kitchens.

5.3.In ducted use;

In ducted use, extractor fan should be connected to an air outlet to send the

air out. In order to use your chimney hood efficiently, make sure length of the

pipe system between the chimney hood and the air outlet should be short.

Your product has been manufactured suitable for ducted and non-ducted

use.

5.4.Round Charcoal Filter

In kitchens with no duct, a round charcoal filter should be reintroduced the

clean air into the kitchen. You can obtain the round filter from your service or

dealer.

5.5.Use of Charcoal Filter

 Our products allow the installation of charcoal filter

 Regardless of use of charcoal filters or not, grease filters should be

installed on the product. Do not use your product without grease filter.

 Use of charcoal ﬁlteris as follows.

 Cut off the device power before replacing charcoal ﬁlter.

 Charcoal ﬁlter is used in the kitchens with no duct therefore should be

replaced in every 3-5 months depending on the frequency of use.

 Charcoal ﬁlter should never be washed.

5.6Installation of Charcoal Filter

 Charcoal ﬁlters are used in the kitchens with no duct.

 Charcoal ﬁlters are installed onto both sides of the fan as shown in Figure

10 by turning 10 degrees clock-wise.

 When uninstalling, reverse the same procedure.

5.7Use of Aluminum Cartridge Filter

 Aluminum cartridge ﬁlter holds dust and grease in the air. Chimney hood

should never be used without aluminum cartridge ﬁlter. Figure 11
