EDS-728 Series User’s Manual Getting Started

2-2

RS-232 Console Configuration (115200, None, 8, 1, VT100)

NOTE

Connection Caution!

1. You cannot connect to the EDS-728 simultaneously by serial console and Telnet.

2. You can connect to the EDS-728 simultaneously by web browser and serial console, or by

web browser and Telnet.

However, we strongly suggest that you do NOT use more than one connection method at the

same time. Following this advice will allow you to maintain better control over the

configuration of your EDS-728.

NOTE

We recommend using Moxa PComm Terminal Emulator, which can be downloaded free of

charge from Moxa’s website.

Before running PComm Terminal Emulator, use an RJ45 to DB9-F (or RJ45 to DB25-F) cable to

connect the EDS-728’s RS-232 Console port to your PC’s COM port (generally COM1 or COM2,

depending on how your system is set up).

After installing PComm Terminal Emulator, take the following steps to access the RS-232 Console

utility.

1. From the Windows desktop, click on Start  Programs  PCommLite2.5  Terminal

Emulator.

2. Select Open under Port Manager to open a new connection.
