- 14 -
Power
Input Voltage
24/48 VDC
Input Current
5.5/2.6 A
Connection
Removable 4-contact terminal block
Overload Current
Protection
12 A
Reverse Polarity
Protection
Present
Conformance to UL
standards
Always use an “isolated power supply” to
conform to the UL 508 standard.
Note: We strongly recommend using an isolated power supply with
maximum output current of 7.5 A due to the power de-
rating issue of the
power supply at high operating temperatures. Moreover, without
galvanic isolation between the redundant power input
s of this device, the
V1+ and V2+ should use the same voltage.
Physical Characteristics
Housing
Metal, IP30 protection
Dimensions
50 x 115 x 70 mm
Weight
275 g
Installation DIN-Rail Mounting, Wall Mounting (with optional
kit)
Environmental Limits
Operating
Temperature
Standard models: 0 to 60°C (32 to 140°F)
Wide temp. models: -40 to 75°C (-40 to 167°F)
Storage Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity
5 to 95% (non-condensing)
Regulatory Approvals
EMI
FCC Part 15, CISPR (EN55022) class A
EMS
EN61000-4-2 (ESD), Level 3
EN61000-4-3 (RS), Level 3
EN61000-4-4 (EFT), Level 3
EN61000-4-5 (Surge), Level 3
EN61000-4-6 (CS), Level 3
EN61000-4-8, Level 5
Shock
IEC 60068-2-27
Freefall
IEC 60068-2-32
Vibration
IEC 60068-2-6
Warranty
Time Period
5 years
Details
www.moxa.com/warranty
Technical Support Contact Information
www.moxa.com/support
Moxa Americas:
Toll
-free: 1-888-669-2872
Tel:
1-714-528-6777
Fax:
1-714-528-6778
Moxa China (Shanghai office):
Toll
-free: 800-820-5036
Tel:
+86-21-5258-9955
Fax:
+86-21-5258-5505
Moxa Europe
:
Tel:
+49-89-3 70 03 99-0
Fax:
+49-89-3 70 03 99-99
Moxa Asia
-Pacific:
Tel:
+886-2-8919-1230
Fax:
+886-2-8919-1231
