- 2 -
Overview
The EDS-P206A-4PoE series industrial Ethernet switches are entry-level
industrial 6-port PoE Ethernet switches that support IEEE 802.3, IEEE
802.3u, and IEEE 802.3x, with 10/100M, full/half-duplex, MDI/MDIX
auto-sensing, IEEE 802.3af, and IEEE 802.3at.
The EDS-P206A-4PoE series provides 24/48 VDC redundant power inputs
that can be connected simultaneously to a live DC power source. The
switches are available with a standard operating temperature range from
0 to 60°C, or with a wide operating temperature range from -40 to 75°C,
and their IP30 metal housing makes them rugged enough for any harsh
industrial environment.
To provide greater versatility for use with applications from different
industries, the EDS-P206A-4PoE switches also allow users to enable or
disable broadcast storm protection with DIP switches on the outer panel.
The EDS-P206A-4PoE switches can be easily installed on a DIN-Rail or in
distribution boxes. The DIN-Rail mounting capability and IP30 metal
housing with LED indicators make the plug-and-play EDS-P206A-4PoE
switches reliable and easy to use.
NOTE
Throughout this Hardware Installation Guide, we use EDS as an
abbreviation for Moxa EtherDevice Switch:
EDS = Moxa EtherDevice Switch
Package Checklist
Your EDS is shipped with the following items. If any of these items are
missing or damaged, please contact your customer service
representative for assistance.
• Moxa EtherDevice™ Switch
• Hardware Installation Guide
• Warranty card
Features
High-wattage Power-over-Ethernet
• Up to 30 watts per PoE port
• Active circuit protection
• Auto disconnection for over-voltage or under-voltage
• Power consumption detection and classification
High Performance Network Switching Technology
• 10/100BaseT(X) (RJ45 connector), 100BaseFX (SC/ST connector,
multi/single-mode)
• 10/100M, Full/Half-Duplex, MDI/MDIX auto-sensing
• IEEE 802.3/802.3u/802.3x
• Store and Forward switching process type, 1K address entries
Rugged Design
• Redundant dual 24/48 VDC power input
• Operating temperature range from 0 to 60°C, or extended operating
temperature of -40 to 75°C for “T” models.
• IP30 metal housing
• DIN-Rail or panel mounting capability
