4
www.moxa.com
info@moxa.com
Industrial Ethernet Solutions
SFP-1FE Series
1-port Fast Ethernet SFP modules
› IEEE 802.3u compliant
› Differential PECL inputs and outputs
› TTL signal detect indicator
› Hot pluggable LC duplex connector
› Class 1 laser product; complies with EN 60825-1
EN : 60825
Interface
Ethernet Ports:1
Connectors:DuplexLCConnector
Optical Fiber
Fast Ethernet
SFP-M SFP-S SFP-L
Wavelength 1300nm 1310nm 1550nm
Max.TX -8dBm 0dBm 0dBm
Min.TX -18dBm -5dBm -5dBm
RXSensitivity -34dBm -34dBm -34dBm
LinkBudget 26dB 29dB 29dB
TypicalDistance 4km
a
40km
b
80km
b
Saturation 0dBm -3dBm -3dBm
a.50/125μmor62.5/125μm,800MHz*km@1300nm
multi-modefiberopticcable
b.9/125μmsingle-modefiberopticcable
Environmental Limits
Operating Temperature:-40to85°C(-40to185°F)
Storage Temperature:-40to85°C(-40to185°F)
Ambient Relative Humidity:5to95%(non-condensing)
Available Models Port Interface
Wide Temperature
(-40 to 85˚C)
100BaseFX, Multi-mode,
LC Connector, 4 km
100BaseFX, Single-mode,
LC Connector, 40 km
100BaseFX, Single-mode,
LC Connector, 80 km
SFP-1FEMLC-T
1 – –
SFP-1FESLC-T
– 1 –
SFP-1FELLC-T
– – 1
Ordering Information
Specifications
Rear View
13.4 (0.5)
45.0 (1.8)
6.3 (0.2)
55.5 (2.2)
56.6 (2.2)
8.4 (0.3)
13.4 (0.5)
14.0 (0.6)
13.7 (0.5)
8.2
(0.3)
Side View
Top View
Dimensions
Unit:mm(inch)
Standards and Certications
Safety:UL60950-1,TÜV
Marine:DNV,GL,LR,NK
Warranty
Warranty Period:5years
Details:Seewww.moxa.com/warranty
Available Models
The SFP-1FE series modules can be used with the following products:
IM-G7000A-4GSFP,IM-G7000-4GSFP,ICS-G7826A/G7828Aseries,ICS-G7826/G7828series,ICS-G7526A/G7528A
series,ICS-G7526/G7528series,IKS-G6524A/G6824Aseries,IKS-G6524/G6824series,IKS-6726A/6728Aseries,
IKS-6726/6728series,IM-6700A-8SFP,IM-6700-8SFP,EDS-611/619series,EDS-G516Eseries,EDS-G512Eseries,
EDS-G509series,EDS-510Eseries,EDS-G308-2SFP,EDS-210Aseries,IKS-6728A-8PoEseries,IKS-6728-8PoEseries,EDS-P510A-8PoEseries,
EDS-P510series,PM-7200-8SFP,EDR-G903/G902series,PT-7528series,PT-G7509series,PM-7500-2GTXSFP,PM-7500-4GTXSFP
Package Checklist
• SFP-1FEmodule
• Warrantycard
