Moxa TN-5518A-8PoE-2GTX-WV-CT-T [13/36] Explanation of current status items
![Moxa TN-5518A-8PoE-2GTX-WV-CT-T [13/36] Explanation of current status items](/views2/1197378/page13/bgd.png)
Communication Redundancy Turbo Ring
2-8
Explanation of “Current Status” Items
Now Active
It shows which communication protocol is in use: Turbo Ring, Turbo Ring V2, RSTP, or none.
Master/Slave
It indicates whether or not this switch is the Master of the Turbo Ring. (This field appears only when Turbo Ring
or Turbo Ring V2 modes are selected.)
NOTE
The user does not need to set the master to use Turbo Ring. If master is
not
set, the Turbo Ring protocol will
assign master status to one of the
switches
in the ring. The master is only used to determine which segment
serves as the backup path.
Redundant Ports Status (1st Port, 2nd Port)
Ring Coupling Ports Status (Coupling Port, Coupling Control Port)
The “Ports Status” indicators show Forwarding for normal transmission, Blocking if this port is connected to
a backup path and the path is blocked, and Link down if there is no connection.
Explanation of “Settings” Items
Redundancy Protocol
Setting Description Factory Default
Turbo Ring Select this item to change to the Turbo Ring configuration page.
None
Turbo Ring V2 Select this item to change to the Turbo Ring V2 configuration page.
Turbo Ring V2 with
DRC (Dynamic Ring
Coupling)
Select this item to change to the Turbo Ring V2 with DRC
configuration page.
Turbo Chain Select this item to change to the Turbo Chain configuration page.
RSTP (IEEE 802.1W/
802.1D-2004)
Select this item to change to the RSTP configuration page.
None Ring redundancy is not active
Set as Master
Setting Description Factory Default
Enabled Select this switch as Master
Not checked
Disabled Do not select this switch as Master
Redundant Ports
Setting Description Factory Default
1st Port Select any port of the switch to be one of the redundant ports.
See the following table
2nd Port Select any port of the switch to be one of the redundant ports.
See the following table
Default 1st Port Default 2nd Port
EDS-400A Series
EDS-505A/508A/516A Series
The second from the last port The last port
EDS-518A Series Port G1 Port G2
EDS-510A Series Port G2 Port G3
EDS-608/616 The third port of the last module The fourth port of the last module
EDS-611/619 Port G2 Port G3
EDS-728/828 Series Port 1-1 Port 1-2
IKS-6726 Series without Gigabit Ethernet module:
Port 1-1
with Gigabit Ethernet module:
Port 4-1
without Gigabit Ethernet module:
Port 1-2
with Gigabit Ethernet module:
Port 4-2
