Moxa TN-5518A-8PoE-2GTX-WV-CT-T [20/36] Explanation of drc status items
![Moxa TN-5518A-8PoE-2GTX-WV-CT-T [20/36] Explanation of drc status items](/views2/1197378/page20/bg14.png)
Communication Redundancy Turbo Ring
2-15
Explanation of “DRC Status” Items
Coupling Group
The “Coupling Group” indicators show Active for taking the responsibility to maintain the coupling links,
Inactive if the other group of the ring is Active status already.
Coupling Port Status
The “Coupling Ports Status” indicators show Port number + Forwarding for normal transmission. If the
switch is the ring master, it will show the status of two coupling groups using MAC address + Port number
+ Link up. If the coupling port has no connection, it shows MAC address + Port number + Link down.
Explanation of “Ring Settings” Items
Redundancy Protocol
Setting Description Factory Default
Turbo Ring Select this item to change to the Turbo Ring configuration page.
None
Turbo Ring V2 Select this item to change to the Turbo Ring V2 configuration page.
Turbo Ring V2 with
DRC (Dynamic Ring
Coupling)
Select this item to change to the Turbo Ring V2 with DRC
configuration page.
Turbo Chain Select this item to change to the Turbo Chain configuration page
RSTP (IEEE 802.1W/
802.1D-2004)
Select this item to change to the RSTP configuration page.
Set as Master
Setting Description Factory Default
Enabled Select this switch as Master
Disabled
Disabled
Select this switch as Slave or if no master in the ring, it may
choose the switch with smallest MAC address as Master
(Candidate Master)
Redundant Ports
Setting Description Factory Default
1st Port Select any port of the switch to be one of the redundant ports.
See the following table
2nd Port
Select any port of the switch to be one of the redundant ports.
See the following table
Default 1st Port Default 2nd Port
TN-5508A/10A Series 7 8
TN-5516A/18A Series 15 16
DRC Settings
Setting Description Factory Default
Group1/Coupling
Ports
Select any port of the switch to be one of the coupling group 1
port and choose auto, primary, backup as the port role
Port number: None
Role: Auto
Group2/Coupling
Ports
Select any port of the switch to be one of the coupling group 2
port and choose auto, primary, backup as the port role
Port number: None
Role: Auto
