Communication Redundancy Turbo Ring
2-9
IKS-G6524/G6824 Series
ICS-G7526/G7528/
G7826/G7828 Series
The second from the last port The last port
TN-5500/TN-5500A Series
TN-5800 Series
The second from the last Fast
Ethernet port number
The last Fast Ethernet port number
Enable Ring Coupling
Setting Description Factory Default
Enable Select this switch as Coupler
Not checked
Disable Do not select this switch as Coupler
Coupling Port
Setting
Description
Factory Default
Coupling Port Select any port of the switch to be the coupling port See the following table
Coupling Control Port
Setting Description Factory Default
Coupling Control Port Select any port of the EDS to be the coupling control port See the following table
Default Coupling Port
Default Coupling Port Default Coupling Control Port
EDS-400A Series
EDS-505A/508A/516A Series
The fourth from the last port The third from the last port
EDS-518A Series Port 15 Port 16
EDS-510A Series Port 7 Port G1
EDS-608/616 The second port of the last module The first port of the last module
EDS-611/619 Port G1 The last port of the last module
EDS-728/828 Series Port 1-3 Port 1-4
IKS-6726 Series without Gigabit Ethernet module:
Port 1-3
with Gigabit Ethernet module:
Port 1-1
without Gigabit Ethernet module:
Port 1-4
with Gigabit Ethernet module:
Port 1-2
IKS-G6524/G6824 Series
ICS-G7526/G7528/
G7826/G7828 Series
The fourth from the last port The third from the last port
TN-5500/TN-5500A Series
TN-5800 Series
The fourth from the last Fast Ethernet
port number
The third from the last Fast Ethernet
port number
