Communication Redundancy Turbo Ring
2-11
Explanation of “Settings” Items
Redundancy Protocol
Setting
Description
Factory Default
Turbo Ring
Select this item to change to the Turbo Ring configuration page.
None
Turbo Ring V2
Select this item to change to the Turbo Ring V2 configuration page.
Turbo Ring V2 with
DRC (Dynamic Ring
Coupling)
Select this item to change to the Turbo Ring V2 with DRC
configuration page.
Turbo Chain
Select this item to change to the Turbo Chain configuration page
RSTP (IEEE 802.1W/
802.1D-2004)
Select this item to change to the RSTP configuration page.
None
Ring redundancy is not active
Enable Ring 1
Setting
Description
Factory Default
Enabled
Enable the Ring 1 settings
Not checked
Disabled
Disable the Ring 1 settings
Not checked
Enable Ring 2*
Setting
Description
Factory Default
Enabled
Enable the Ring 2 settings
Not checked
Disabled
Disable the Ring 2 settings
Note: You should enable both Ring 1 and Ring 2 when using the Dual-Ring architecture.
Set as Master
Setting
Description
Factory Default
Enabled
Select this EDS as Master
Not checked
Disabled
Do not select this EDS as Master
Redundant Ports
Setting
Description
Factory Default
1st Port
Select any port of the EDS to be one of the redundant ports.
See the following table
2nd Port
Select any port of the EDS to be one of the redundant ports.
See the following table
Default Ports
Default 1st Port
Default 2nd Port
EDS-400A Series
EDS-505A/508A/516A Series
The second from the last port
The last port
EDS-518A Series
Port G1
Port G2
EDS-510A Series
Port G2
Port G3
EDS-608/616
The third port of the last module
The fourth port of the last module
EDS-611/619
Port G2
Port G3
EDS-728/828 Series
Port 1-1
Port 1-2
IKS-6726 Series
without Gigabit Ethernet module:
Port 1-1
with Gigabit Ethernet module: Port 4-1
without Gigabit Ethernet module:
Port 1-2
with Gigabit Ethernet module: Port 4-2
IKS-G6524/G6824 Series
ICS-G7526/G7528/
G7826/G7828 Series
The second from the last port
The last port
TN-5500/TN-5500A Series
TN-5800 Series
The second from the last Fast Ethernet
port number
The last Fast Ethernet port number
