Communication Redundancy Turbo Ring
2-12
NOTE
For EDS-600 Series switches, there are certain restrictions on which ports can be used as ring ports.
• You may use any two of the non-Gigabit ports as the ring ports; however, the two ring ports for a particular
switch must be on the same module.
• If you need to use Gigabit ports as ring ports, you must use the second and third Gigabit ports (G2 and G3)
as the ring ports (but do NOT use G1).
Enable Ring Coupling
Setting
Description
Factory Default
Enable
Select this EDS as Coupler
Not checked
Disable
Do not select this EDS as Coupler
Coupling Mode
Setting
Description
Factory Default
Dual Homing
Select this item to change to the Dual Homing configuration
page
See the following
table
Ring Coupling
(backup)
Select this item to change to the Ring Coupling (backup)
configuration page
See the following
table
Ring Coupling
(primary)
Select this item to change to the Ring Coupling (primary)
configuration page
See the following
table
Default Dual Homing Ports
Default Dual Homing (Primary)
Default Dual Homing (Backup)
EDS-400A Series
EDS-505A/508A/516A Series
The fourth from the last port
The third from the last port
EDS-518A Series
Port 15
Port 16
EDS-510A Series
Port G1
Port G2
EDS-608/616
The first port of the first module
The second port of the first module
EDS-611/619
Port G1
The last port of the last module
EDS-728/828 Series
N/A
N/A
IKS-6726 Series
without Gigabit Ethernet module: Port
1-5
with Gigabit Ethernet module: Port 1-3
without Gigabit Ethernet module: Port
1-6
with Gigabit Ethernet module: Port 1-4
IKS-G6524/G6824 Series
ICS-G7526/G7528/
G7826/G7828 Series
The fourth from the last port
The third from the last port
TN-5500/TN-5500A Series
TN-5800 Series
The first port number
The first port number
