MartinLogan Descent [3/20] Installation in brief

3Installation in Brief 3

INSTALLATION IN BRIEF

We know that you are eager to hear your new Descent sub-

woofer, so this section is provided to allow fast and easy

set up. Once you have it operational, please take the time

read, in depth, the rest of the information in this manual.

It will give you perspective on how to attain the greatest

possible performance from this most exacting woofer system.

If you experience any difficulties in setup or operation of your

Descent subwoofer, please refer to the Room Acoustics,

Placement or Operation sections of this manual.

Should you encounter a persistent problem that cannot be

resolved, please contact your authorized MartinLogan dealer.

They will provide you with the appropriate technical analysis

to alleviate the situation.

WARNING!

•Hazardous voltages exist inside—do not

remove cover.

•Refer servicing to a qualified technician.

•To prevent fire or shock hazard, do not

expose this module to moisture.

•Turn subwoofer off and unplug

should any abnormal conditions occur .

•Use only with a grounded outlet.

Step 1: Unpacking

Remove your new Descent subwoofer from its packing.

Step 2: Placement

Ideally, place the Descent in a corner near the front of the

room. This is a good place to start. Please see the Placement

section (page 11) of this manual for more details.

Step 3: Signal Connection

Use the best interconnect cables you can. High quality cables,

available from your specialty dealer, are recommended and

will give you superior performance.

Attach your preamplifier/processor outputs through cables

to the signal input area located on the Descents rear panel.

Please see the Connections and Control Settings section

(pages 6–10) of this manual for more details.

Step 4: Power Connection (AC) (see warning)

Make sure the level knob is set at 0. Plug the Descent sub-

woofer into a wall outlet and set the power switch above the

AC receptacle to on. Please see the Connections and Control

Settings section (pages 6–10) of this manual for more details.

Step 5: Setting the Controls

Set the level knob to a medium volume position (12 o'clock).

Set the 25Hz Level to 0 (12 o'clock). Set the power switch

on the front of the Descent to ‘Auto’.

Step 6: Listen and Enjoy

Now, you may adjust your system and enjoy!

The lightning bolt flash with arrowhead symbol, within

an equilateral triangle, is intended to alert the user to the

presence of uninsulated “dangerous voltage” within the

product’s enclosure that may be of sufficient magnitude

to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in

the literature accompanying the appliance.
