- 13 -
Auto-negotiation takes place when an RJ45 cable connection is made.
Each time a LINK is enabled. The IMC-101G advertises its capability for
using 10 Mbps, 100 Mbps, or 1000 Mbps transmission speeds, with the
device at the other end of the cable expected to advertise similarly.
Depending on what type of device is connected, this will result in
agreement to operate at a speed of 10 Mbps, 100 Mbps, or 1000 Mbps.
If an IMC-101G’s RJ45 Ethernet port is connected to a non-negotiating
device, it will default to 10 Mbps speed and half-duplex mode, as required
by the IEEE 802.3u standard.
Specifications
Technology
Standards
IEEE802.3, 802.3u, 802.3x, 802.3z/ab, Link
Fault Pass-through
Interface
RJ45 Ports 10/100/1000BaseT(X) auto-negotiation speed,
F/H duplex mode, and auto MDI/MDI-X
connection
SFP Ports
1000Base SFP slot
LED Indicators
PWR1, PWR2, FAULT, 10/100M(TP port), 1000M
(TP and SFP port)
DIP Switches
Port break alarm mask, Link Fault Pass-through,
SFP AN/Force
Alarm Contact One relay output with current-carrying capacity
of 1 A @ 24 VDC, resistive
Optical Fiber: 1000BaseSX/LSX/LX/LH/LHX/ZX/EZX
(Supports SFP-1G Series module only)
Gigabit Ethernet
Wavelength
Max Tx
(dBm)
Min Tx
(dBm)
Rx Sensitivity
(dBm)
Link Budget
(dB)
Typical
Distance
(dBm)
SFP-SX 850 nm -4 -9.5 -18 8.5 550 m
a
0
SFP-LSX 1310 nm -1 -9 -19 10 2 km
b
-3
SFP-LX 1310 nm -3 -9.5 -20 10.5 10 km
c
-3
SFP-LH 1310 nm -2 -8 -23 15 30 km
c
-3
SFP-LHX 1310 nm 1 -4 -24 20 40 km
c
-3
SFP-ZX 1550 nm 5 0 -24 24 80 km
c
-3
SFP-EZX 1550 nm 5 0 -30 30 110 km
c
-3
SFP-EZX-
120
1550 nm 3 -2 -33 31 120 km
c
-8
SFP-10A
TX 1310
nm,
RX 1550 nm
-3 -9 -21 12 10 km
c
-1
SFP-10B
TX 1550 nm,
RX 1310 nm
SFP-20A
TX 1310 nm,
RX 1550 nm
-2 -8 -23 15 20 km
c
-1
SFP-20B
TX 1550 nm,
RX 1310 nm
SFP-40A
TX 1310 nm,
RX 1550 nm
2 -3 -23 20 40 km
c
-1
SFP-40B
TX 1550 nm,
RX 1310 nm
