![Moxa AWK-1127-PoE-T Руководство по аппаратной части онлайн [12/13] 170061](/views2/1198017/page12/bgc.png)
- 12 -
RJ45 Ports
1, 10/100BaseT(X) auto negotiation speed, F/H
duplex mode, and auto MDI/MDI-X connection
Console Port
RS-232 (RJ45-type)
Reset
Present
LED Indicators
PWR, FAULT, STATE, SIGNAL, WLAN, LAN, TX, RX
Serial Communication Parameters
Data Bits
5, 6, 7, 8
Stop Bits
1, 1.5, 2
Parity
None, Even, Odd, Space, Mark
Flow Control
RTS/CTS, XON/XOFF
Baudrate
50 bps to 921.6 kbps
Serial Data Log
256 KB
Serial Signals
RS-232
DSR, RTS, GND, TxD, RxD, DCD, CTS, DTR
RS-422
Tx+, Tx-, Rx+, Rx-, GND
RS-485 (2-wire)
Data+, Data-, and GND
RS-485 (4-wire)
Tx+, Rx+, Tx-, Rx+, and GND
Physical Characteristics
Housing
Metal, providing IP30 protection
Weight
400 g (0.9 lb)
Dimensions
50 x 115 x 70 mm(1.98 x 4.53 x 2.76 in)
Installation
DIN-rail mounting, wall mounting (with optional kit)
Environmental Limits
Operating
Temperature
Standard Models: 0 to 60°C (32 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage
Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity
5% to 95% (non-condensing)
Power Requirements
Input Voltage
12 to 48 VDC, redundant dual DC power inputs or 48
VDC Power-over-Ethernet (IEEE 802.3af
compliant)*
*PoE is only available for the AWK-1127-PoE
Connector
4-pin removable terminal block
Power Consumption
12 to 48 VDC, 0.16 to 0.55 A
Reverse Polarity
Protection
Present
Standards and Certifications
Safety
UL 60950-1, EN 60950-1
EMC
EN 301 489-1/17; FCC Part 15, Subpart B; EN
55022/55024
Radio
EN 300 328, EN 301 893, TELEC, FCC ID
SLE-WAPN003
Note: Please check Moxa’s website for the most up-to-date certification
status.
Reliability
MTBF
392,209 hrs.
Warranty
Warranty Period
5 years
Details
See www.moxa.com/support/warranty.aspx
