AirWorks AWK-1131A Introduction
1-6
The following table summarizes how to read the device’s wireless settings from the LED displays. More
information is available in Chapter 3 in the “Basic Wireless Settings” section.
LED Color State Description
Front Panel LED Indicators (System)
PWR Green
On Power is being supplied from power input 1&2.
Off Power is not being supplied from power input 1&2.
FAULT Red
Blinking (fast at 0.5-sec intervals)
Cannot get an IP address from the DHCP server
Blinking (slow at 1-sec intervals) IP address conflict
Off Error condition does not exist.
STATE
Green/
Red
Green Software Ready
Green/Blinking at 1-sec intervals The AWK has been located by AWK Search Utility.
Red Booting error condition
SIGNAL
(5 LEDs)
Green
On Signal level(for Client mode only)
Off
WLAN
Green
On
WLAN function is in Client mode and AWK has
established a link with an AP.
Blinking WLAN data communication is run in Client mode
Off
WLAN is not in Client Mode or AWK has not
established a link with an AP.
Amber
On WLAN function is in AP mode.
Blinking WLAN’s data communication is run in AP mode
Off WLAN is not in use or not working properly
TP Port(RJ45) LED Indicators (Port Interface)
1000M Green
On TP port’s 1000Mbps link is active.
Blinking Data is being transmitted at 1000 Mbps
Off TP port’s 1000Mbps link is inactive.
10/100M Amber
On TP port’s 10/100Mbps link is active.
Blinking Data is being transmitted at 10/100 Mbps
Off TP port’s 10/100Mbps link is inactive.
ATTENTION
When
the system fails to boot, the LEDs for STATE (Green), FAULT, and WLAN will all light up
simultaneously and blink at one
-second intervals. This might be due to improper operation or issues su
ch as
an unexpected shutdown
while updating the firmware. To instruction on recovering the firmware, refer to
the
“Firmware Recovery”
section in Chapter 6.
Beeper
The beeper emits two short beeps when the system is ready.
